Product Description
Solvent Automatic Cleaning
14L of wash solvent is pumped through 14 jets to flush the fluid passage and exterior of 2 spray guns in under 1 minute. A final rinse of 100 cc of clean solvent and air flush completes automatic cleaning.
Automatic Cleaning is faster than cleaning by hand, allowing more cars to be painted each day.
Automatic Cleaning provides a consistent result as opposed to cleaning by hand.
Additional manual cleaning, when required, is provided by a flow-through brush. Solvent flow is activated by a foot pedal.
Automatic cleaning greatly reduces the painter's exposure to solvent for a healthier environment.Â
Spray guns are cleaned with solvent in an enclosed tank; the operation is "Hands Free". The vent automatically extracts fumes when the lid is raised.Â
If the lid is accidently raised during cleaning, the operation stops, to prevent solvent exposure.
Wash solvent is reused until dirty, reducing solvent consumption.
Features
Top loading; cleans 2 guns.
Automatic cleaning cycle consists of wash, clean rinse and air flush.
Powered by a dual diaphragm pump, 12L per minute capacity.
The air plug with air flow prevents solvent from entering the air passage of the spray gun during cleaning.
Cleaning tank and delivery tubes are constructed from 304 grade stainless steel for long life.
Waterborne Manual Cleaning
Waterborne spray guns are cleaned effectively with 3 cleaning tools.
Wash gun delivers high pressure water to flush the fluid passage in under 15 seconds.
Flow-through brush removes paint from the outside of the spray gun.
Air gun dries the spray gun.
The used water can be recovered and reused reducing waste water consumption and disposal costs.
Features
Stainless steel cleaning tank for long life.
Wash gun and brush are powered by a 5cm (2") dual diaphragm pump.Â
The used water is treated then filtered.
Waste paint clumps at the surface of the water. The filter captures the waste paint, allowing the clean water to pass to the capture bucket.
Used water can be reclaimed up to 8 times reducing consumption and disposal costs.
General Features
Complete with pressure regulator. Minimum air pressure is 6 bar (85 psi).
Dimensions: 119 cm w x 43 cm d x 117 cm h
Dimensions: 47" w x 17" d x 46" h
Weight: 77 kg
